Profile Page Save Image Data In SharedPreferences


.
Saving Image Data In SharedPreferences
Using Android Studio 1.4
It is possible to store image in SharedPreferences byconverting it into Base64 string.

1) Start Up

Follow previous tutorial or download start up project MyProfile3-first-login.zip.

2) Edit Manifest

<?xml version="1.0" encoding="utf-8"?>
<manifest xmlns:android="http://schemas.android.com/apk/res/android"
   package="com.notarazi.myprofile" >
   <uses-feature android:name="android.hardware.camera"
       android:required="false" />
   <uses-permission android:name="android.permission.CAMERA" />
   <uses-permission android:name="android.permission.WRITE_EXTERNAL_STORAGE" />
   <application
       android:allowBackup="true"
       android:icon="@mipmap/ic_launcher"
       android:label="@string/app_name"
       android:supportsRtl="true"
       android:theme="@style/AppTheme" >
       <activity android:name=".MyProfile"
           android:configChanges="keyboardHidden|orientation|screenSize">
           <intent-filter>
               <action android:name="android.intent.action.MAIN" />
               <category android:name="android.intent.category.LAUNCHER" />
           </intent-filter>
       </activity>
   </application>
</manifest>
Get permission to use Camera and Gallery resource.
Prevent the application from resetting the image view when device orientation changes.

3) Edit Layout

Add a method call (setProfilePhoto) and another Image View (usersavedphoto).
The second Image View (usersavedphoto) is used to check that the image has been successfully encoded/decoded to/from Base64 string.
<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
   xmlns:tools="http://schemas.android.com/tools"
   xmlns:app="http://schemas.android.com/apk/res-auto"
   android:layout_width="match_parent"
   android:layout_height="match_parent"
   android:paddingLeft="@dimen/activity_horizontal_margin"
   android:paddingRight="@dimen/activity_horizontal_margin"
   android:paddingTop="@dimen/activity_vertical_margin"
   android:paddingBottom="@dimen/activity_vertical_margin"
   tools:context=".MyProfile">
   <ScrollView xmlns:android="http://schemas.android.com/apk/res/android"
       xmlns:tools="http://schemas.android.com/tools"
       android:layout_width="match_parent"
       android:layout_height="match_parent"
       android:orientation="vertical" >
       <LinearLayout
           android:layout_width="match_parent"
           android:layout_height="match_parent"
           android:orientation="vertical" >
           <com.joooonho.SelectableRoundedImageView
               android:id="@+id/userphoto"
               android:layout_width="120dp"
               android:layout_height="120dp"
               android:layout_gravity="center"
               android:scaleType="centerCrop"
               android:src="@drawable/photo"
               app:sriv_border_color="#FFCC00"
               app:sriv_border_width="2dp"
               app:sriv_oval="true" />
           <TextView
               android:layout_width="match_parent"
               android:layout_height="match_parent"
               android:layout_marginTop="20dp"
               android:text="Personal Profile"/>
           <EditText
               android:id="@+id/username"
               android:layout_width="match_parent"
               android:layout_height="match_parent"
               android:inputType="text"
               android:hint="Name"/>
           <EditText
               android:id="@+id/userphone"
               android:layout_width="match_parent"
               android:layout_height="match_parent"
               android:inputType="phone"
               android:hint="Phone number"/>
           <EditText
               android:id="@+id/useremail"
               android:layout_width="match_parent"
               android:layout_height="match_parent"
               android:inputType="textEmailAddress"
               android:hint="Email"/>
           <Button
               android:layout_width="match_parent"
               android:layout_height="match_parent"
               android:text="OK"
               android:onClick="setProfilePhoto"
               />
           <com.joooonho.SelectableRoundedImageView
               android:id="@+id/usersavedphoto"
               android:layout_width="20dp"
               android:layout_height="20dp"
               android:layout_gravity="center"
               android:scaleType="centerCrop"
               android:src="@android:drawable/ic_menu_gallery"
               app:sriv_border_color="#FFCC00"
               app:sriv_border_width="2dp"
               app:sriv_oval="true" />
       </LinearLayout>
   </ScrollView>
</RelativeLayout>

4) Edit MainActivity (convert image)

Bind imageview object to imageview ui.
Get bitmap from the imageview object.
Convert bitmap to string
Save string to sharedpreferences
package com.notarazi.myprofile;
import android.content.SharedPreferences;
import android.graphics.Bitmap;
import android.graphics.BitmapFactory;
import android.os.Bundle;
import android.support.v7.app.AppCompatActivity;
import android.util.Base64;
import android.view.View;
import android.widget.EditText;
import android.widget.ImageView;
import java.io.ByteArrayOutputStream;
public class MyProfile extends AppCompatActivity {
   @Override
   protected void onCreate(Bundle savedInstanceState) {
       super.onCreate(savedInstanceState);
       setContentView(R.layout.activity_my_profile);
       checkFirstLogin();
       prepareForm();
   }
   private void prepareForm() {
       SharedPreferences preferences = getSharedPreferences("myprefs",MODE_PRIVATE);
       EditText etUserName=(EditText)findViewById(R.id.username);
       EditText etUserPhone=(EditText)findViewById(R.id.userphone);
       EditText etUserEmail=(EditText)findViewById(R.id.useremail);
       // If value for key not exist then return second param value - In this case "..."
       etUserName.setText(preferences.getString("username""..."));
       etUserPhone.setText(preferences.getString("userphone""..."));
       etUserEmail.setText(preferences.getString("useremail""..."));
   }
   private void checkFirstLogin() {
       SharedPreferences preferences = getSharedPreferences("myprefs",MODE_PRIVATE);
       // If value for key not exist then return second param value - In this case true
       if (preferences.getBoolean("firstLogin"true)) {
           initProfile();
           SharedPreferences.Editor editor = preferences.edit();
           editor.putBoolean("firstLogin"false);
           editor.commit();
       }
   }
   private void initProfile() {
       SharedPreferences preferences = getSharedPreferences("myprefs",MODE_PRIVATE);
       SharedPreferences.Editor editor = preferences.edit();
       editor.putString("username","Demo TryTest");
       editor.putString("userphone","01234567890");
       editor.putString("useremail","demotrytest@gmail.com");
       editor.commit();
   }
   public void setProfilePhoto(View view){
       ImageView ivphoto = (ImageView)findViewById(R.id.userphoto);
       //code image to string
       ivphoto.buildDrawingCache();
       Bitmap bitmap = ivphoto.getDrawingCache();
       ByteArrayOutputStream stream=new ByteArrayOutputStream();
       bitmap.compress(Bitmap.CompressFormat.PNG90, stream);
       byte[] image=stream.toByteArray();
       //System.out.println("byte array:"+image);
       //System.out.println("string:"+img_str);
       String img_str = Base64.encodeToString(image, 0);
       //decode string to image
       String base=img_str;
       byte[] imageAsBytes = Base64.decode(base.getBytes(), Base64.DEFAULT);
       ImageView ivsavedphoto = (ImageView)this.findViewById(R.id.usersavedphoto);
       ivsavedphoto.setImageBitmap(BitmapFactory.decodeByteArray(imageAsBytes,0, imageAsBytes.length)
       );
   }
}


5) Edit MainActivity (save image in sharedpreferences)

package com.notarazi.myprofile;
import android.content.SharedPreferences;
import android.graphics.Bitmap;
import android.graphics.BitmapFactory;
import android.os.Bundle;
import android.support.v7.app.AppCompatActivity;
import android.util.Base64;
import android.view.View;
import android.widget.EditText;
import android.widget.ImageView;
import java.io.ByteArrayOutputStream;
public class MyProfile extends AppCompatActivity {
   @Override
   protected void onCreate(Bundle savedInstanceState) {
       super.onCreate(savedInstanceState);
       setContentView(R.layout.activity_my_profile);
       checkFirstLogin();
       prepareForm();
   }
   private void prepareForm() {
       SharedPreferences preferences = getSharedPreferences("myprefs",MODE_PRIVATE);
       EditText etUserName=(EditText)findViewById(R.id.username);
       EditText etUserPhone=(EditText)findViewById(R.id.userphone);
       EditText etUserEmail=(EditText)findViewById(R.id.useremail);
       // If value for key not exist then return second param value - In this case "..."
       etUserName.setText(preferences.getString("username""..."));
       etUserPhone.setText(preferences.getString("userphone""..."));
       etUserEmail.setText(preferences.getString("useremail""..."));
   }
   private void checkFirstLogin() {
       SharedPreferences preferences = getSharedPreferences("myprefs",MODE_PRIVATE);
       // If value for key not exist then return second param value - In this case true
       if (preferences.getBoolean("firstLogin"true)) {
           initProfile();
           SharedPreferences.Editor editor = preferences.edit();
           editor.putBoolean("firstLogin"false);
           editor.commit();
       }
   }
   private void initProfile() {
       SharedPreferences preferences = getSharedPreferences("myprefs",MODE_PRIVATE);
       SharedPreferences.Editor editor = preferences.edit();
       editor.putString("username","Demo TryTest");
       editor.putString("userphone","01234567890");
       editor.putString("useremail","demotrytest@gmail.com");
       editor.commit();
   }
   public void setProfileImage(View view){
       ImageView ivphoto = (ImageView)findViewById(R.id.userphoto);
       //code image to string
       ivphoto.buildDrawingCache();
       Bitmap bitmap = ivphoto.getDrawingCache();
       ByteArrayOutputStream stream=new ByteArrayOutputStream();
       bitmap.compress(Bitmap.CompressFormat.PNG90, stream);
       byte[] image=stream.toByteArray();
       //System.out.println("byte array:"+image);
       //System.out.println("string:"+img_str);
       String img_str = Base64.encodeToString(image, 0);
       //decode string to image
       String base=img_str;
       byte[] imageAsBytes = Base64.decode(base.getBytes(), Base64.DEFAULT);
       ImageView ivsavedphoto = (ImageView)this.findViewById(R.id.usersavedphoto);
       ivsavedphoto.setImageBitmap(BitmapFactory.decodeByteArray(imageAsBytes,0, imageAsBytes.length) );
       //save in sharedpreferences
       SharedPreferences preferences = getSharedPreferences("myprefs",MODE_PRIVATE);
       SharedPreferences.Editor editor = preferences.edit();
       editor.putString("userphoto",img_str);
       editor.commit();
   }
}

6) Edit MainActivity (initialize Image Views with the stored image)

package com.notarazi.myprofile;
import android.content.SharedPreferences;
import android.graphics.Bitmap;
import android.graphics.BitmapFactory;
import android.os.Bundle;
import android.support.v7.app.AppCompatActivity;
import android.util.Base64;
import android.view.View;
import android.widget.EditText;
import android.widget.ImageView;
import java.io.ByteArrayOutputStream;
public class MyProfile extends AppCompatActivity {
   @Override
   protected void onCreate(Bundle savedInstanceState) {
       super.onCreate(savedInstanceState);
       setContentView(R.layout.activity_my_profile);
       checkFirstLogin();
       prepareForm();
   }
   private void prepareForm() {
       SharedPreferences preferences = getSharedPreferences("myprefs",MODE_PRIVATE);
       EditText etUserName=(EditText)findViewById(R.id.username);
       EditText etUserPhone=(EditText)findViewById(R.id.userphone);
       EditText etUserEmail=(EditText)findViewById(R.id.useremail);
       ImageView ivUserPhoto=(ImageView) findViewById(R.id.userphoto);
       ImageView ivUserSavedPhoto=(ImageView) findViewById(R.id.usersavedphoto);
       // If value for key not exist then return second param value - In this case "..."
       etUserName.setText(preferences.getString("username""..."));
       etUserPhone.setText(preferences.getString("userphone""..."));
       etUserEmail.setText(preferences.getString("useremail""..."));
       String img_str=preferences.getString("userphoto""");
       if (!img_str.equals("")){
           //decode string to image
           String base=img_str;
           byte[] imageAsBytes = Base64.decode(base.getBytes(), Base64.DEFAULT);           ivUserPhoto.setImageBitmap(BitmapFactory.decodeByteArray(imageAsBytes, 0, imageAsBytes.length) );           ivUserSavedPhoto.setImageBitmap(BitmapFactory.decodeByteArray(imageAsBytes, 0, imageAsBytes.length) );
       }
   }
   private void checkFirstLogin() {
       SharedPreferences preferences = getSharedPreferences("myprefs",MODE_PRIVATE);
       // If value for key not exist then return second param value - In this case true
       if (preferences.getBoolean("firstLogin"true)) {
           initProfile();
           SharedPreferences.Editor editor = preferences.edit();
           editor.putBoolean("firstLogin"false);
           editor.commit();
       }
   }
   private void initProfile() {
       SharedPreferences preferences = getSharedPreferences("myprefs",MODE_PRIVATE);
       SharedPreferences.Editor editor = preferences.edit();
       editor.putString("username","Demo TryTest");
       editor.putString("userphone","01234567890");
       editor.putString("useremail","demotrytest@gmail.com");
       editor.commit();
   }
   public void setProfileImage(View view){
       ImageView ivphoto = (ImageView)findViewById(R.id.userphoto);
       //code image to string
       ivphoto.buildDrawingCache();
       Bitmap bitmap = ivphoto.getDrawingCache();
       ByteArrayOutputStream stream=new ByteArrayOutputStream();
       bitmap.compress(Bitmap.CompressFormat.PNG90, stream);
       byte[] image=stream.toByteArray();
       //System.out.println("byte array:"+image);
       //System.out.println("string:"+img_str);
       String img_str = Base64.encodeToString(image, 0);
       //decode string to image
       String base=img_str;
       byte[] imageAsBytes = Base64.decode(base.getBytes(), Base64.DEFAULT);
       ImageView ivsavedphoto = (ImageView)this.findViewById(R.id.usersavedphoto);
       ivsavedphoto.setImageBitmap(BitmapFactory.decodeByteArray(imageAsBytes,0, imageAsBytes.length) );
       //save in sharedpreferences
       SharedPreferences preferences = getSharedPreferences("myprefs",MODE_PRIVATE);
       SharedPreferences.Editor editor = preferences.edit();
       editor.putString("userphoto",img_str);
       editor.commit();
   }
}
OUTCOME.
(If there is a profile photo stored in shared preferences, the small image below the button will display it. Otherwise it will display a gallery icon as in step no.3).

DOWNLOAD

REFERENCES


.

3 comments:
