Android Development Steps: Android Fragment SQLite 1

Android Fragment SQLite 1

This tutorial is adapted from http://androidopentutorials.com/android-sqlite-example/.

1) Startup

Follow Startup Project Tutorial or Download Zip here.

2) Disable Floating Action Button

The startup project contains Floating Action Button which will not be used in this tutorial.

Disable the button in activity_main.xml and MainActivity.java

File Name: Res/layout/activity_main.xml

<?xml version="1.0" encoding="utf-8"?>

<android.support.design.widget.CoordinatorLayout

xmlns:android="http://schemas.android.com/apk/res/android"

xmlns:app="http://schemas.android.com/apk/res-auto"

xmlns:tools="http://schemas.android.com/tools" android:layout_width="match_parent"

android:layout_height="match_parent" android:fitsSystemWindows="true"

tools:context=".MainActivity">

<android.support.design.widget.AppBarLayout android:layout_height="wrap_content"

android:layout_width="match_parent"android:theme="@style/AppTheme.AppBarOverlay">

<android.support.v7.widget.Toolbar android:id="@+id/toolbar"

android:layout_width="match_parent" android:layout_height="?attr/actionBarSize"

android:background="?attr/colorPrimary"app:popupTheme="@style/AppTheme.PopupOverlay" />

</android.support.design.widget.AppBarLayout>

<!--

<android.support.design.widget.FloatingActionButton android:id="@+id/fab"

android:layout_width="wrap_content" android:layout_height="wrap_content"

android:layout_gravity="bottom|end" android:layout_margin="@dimen/fab_margin"

android:src="@android:drawable/ic_dialog_email" />

-->

</android.support.design.widget.CoordinatorLayout>

File Name: MainActivity.java

package com.notarazi.myviewpagertablayout1;

import android.os.Bundle;

import android.support.design.widget.TabLayout;

import android.support.v4.view.ViewPager;

import android.support.v7.app.AppCompatActivity;

import android.support.v7.widget.Toolbar;

import android.view.Menu;

import android.view.MenuItem;

public class MainActivity extends AppCompatActivity {

@Override

protected void onCreate(Bundle savedInstanceState) {

super.onCreate(savedInstanceState);

setContentView(R.layout.activity_main);

Toolbar toolbar = (Toolbar) findViewById(R.id.toolbar);

setSupportActionBar(toolbar);

// Get the ViewPager and set it's PagerAdapter so that it can display items

ViewPager viewPager = (ViewPager) findViewById(R.id.viewpager);

viewPager.setAdapter(new MainFragmentPagerAdapter(getSupportFragmentManager(),

MainActivity.this));

// Give the TabLayout the ViewPager

TabLayout tabLayout = (TabLayout) findViewById(R.id.sliding_tabs);

tabLayout.setupWithViewPager(viewPager);

//FloatingActionButton fab = (FloatingActionButton) findViewById(R.id.fab);

//fab.setOnClickListener(new View.OnClickListener() {

// @Override

// public void onClick(View view) {

// Snackbar.make(view, "Replace with your own action", Snackbar.LENGTH_LONG)

// .setAction("Action", null).show();

// }

//});

}

@Override

public boolean onCreateOptionsMenu(Menu menu) {

// Inflate the menu; this adds items to the action bar if it is present.

getMenuInflater().inflate(R.menu.menu_main, menu);

return true;

}

@Override

public boolean onOptionsItemSelected(MenuItem item) {

// Handle action bar item clicks here. The action bar will

// automatically handle clicks on the Home/Up button, so long

// as you specify a parent activity in AndroidManifest.xml.

int id = item.getItemId();

//noinspection SimplifiableIfStatement

if (id == R.id.action_add) {

return true;

}

return super.onOptionsItemSelected(item);

}

3) Edit Resource Files

File Name: Res/values/colors.xml

<?xml version="1.0" encoding="utf-8"?>

<color name="list_item_bg">#ffffff</color>

<color name="view_divider_color">#BABABA</color>

</resources>

File Name: Res/values/strings.xml

<string name="app_name">AndroidSQLite</string>

<string name="add_emp">Add Employee</string>

<string name="update_emp">Update Employee</string>

<string name="name">Employee Name</string>

<string name="dob">Employee DOB</string>

<string name="salary">Employee Salary</string>

<string name="update">Update</string>

<string name="reset">Reset</string>

<string name="cancel">Cancel</string>

</resources>

File Name: Res/menu/menu_main.xml

Take note that the statement to display menu item as action button uses the tag word “app:” instead of “android:”. Refer the orange highlighted color text below.

<menu xmlns:android="http://schemas.android.com/apk/res/android"

xmlns:app="http://schemas.android.com/apk/res-auto"

xmlns:tools="http://schemas.android.com/tools" tools:context=".MainActivity">

<item

android:id="@+id/action_add"

android:icon="@android:drawable/ic_menu_add"

android:orderInCategory="100"

app:showAsAction="always"

android:title="@string/add_emp"

tools:ignore="AppCompatResource" />

</menu>

File Name: Res/layout/activity_main.xml

No changes were made.

File Name: Res/layout/fragment_page1.xml

(This file follows fragment_add_emp.xml file of the original tutorial)

(Replace the whole content)

<?xml version="1.0" encoding="utf-8"?>

<ScrollView xmlns:android="http://schemas.android.com/apk/res/android"

android:layout_width="match_parent"

android:layout_height="match_parent" >

<RelativeLayout

android:layout_width="wrap_content"

android:layout_height="wrap_content"

android:layout_margin="5dp" >

<EditText

android:id="@+id/etxt_name"

android:layout_width="wrap_content"

android:layout_height="wrap_content"

android:ems="10"

android:hint="@string/name"

android:nextFocusDown="@+id/etxt_dob"

android:singleLine="true" />

<EditText

android:id="@+id/etxt_dob"

android:layout_width="wrap_content"

android:layout_height="wrap_content"

android:layout_below="@+id/etxt_name"

android:hint="@string/dob"

android:nextFocusDown="@+id/etxt_salary"

android:singleLine="true" />

<EditText

android:id="@+id/etxt_salary"

android:layout_width="wrap_content"

android:layout_height="wrap_content"

android:layout_below="@+id/etxt_dob"

android:hint="@string/salary"

android:inputType="numberDecimal"

android:singleLine="true" />

<LinearLayout

android:id="@+id/layout_submit"

android:layout_width="fill_parent"

android:layout_height="wrap_content"

android:layout_below="@+id/etxt_salary"

android:layout_margin="5dp"

android:orientation="horizontal"

android:weightSum="2" >

<Button

android:id="@+id/button_add"

android:layout_width="0dp"

android:layout_height="wrap_content"

android:layout_weight="1"

android:text="@string/add" />

<Button

android:id="@+id/button_reset"

android:layout_width="0dp"

android:layout_height="wrap_content"

android:layout_weight="1"

android:text="@string/reset" />

</LinearLayout>

</RelativeLayout>

</ScrollView>

File Name: Res/layout/fragment_page2.xml

(This file follows fragment_emp_file.xml file of the original tutorial)

(Replace the whole content)

<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"

xmlns:tools="http://schemas.android.com/tools"

android:layout_width="match_parent"

android:layout_height="match_parent"

android:background="#EDEDED" >

<ListView

android:id="@+id/list_emp"

android:layout_width="match_parent"

android:layout_height="match_parent"

android:divider="@color/transparent"

android:dividerHeight="10dp"

android:drawSelectorOnTop="true"

android:footerDividersEnabled="false"

android:padding="10dp"

android:scrollbarStyle="outsideOverlay" />

</RelativeLayout>

File Name: Res/layout/list_item.xml

<?xml version="1.0" encoding="utf-8"?>

<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"

android:layout_width="fill_parent"

android:layout_height="wrap_content"

android:background="@color/list_item_bg"

android:descendantFocusability="blocksDescendants" >

<RelativeLayout

android:id="@+id/layout_item"

android:layout_width="fill_parent"

android:layout_height="wrap_content" >

<TextView

android:id="@+id/txt_emp_id"

android:layout_width="wrap_content"

android:layout_height="wrap_content"

android:padding="6dp" />

<TextView

android:id="@+id/txt_emp_name"

android:layout_width="wrap_content"

android:layout_height="wrap_content"

android:layout_toRightOf="@+id/txt_emp_id"

android:padding="6dp" />

<TextView

android:id="@+id/txt_emp_dob"

android:layout_width="wrap_content"

android:layout_height="wrap_content"

android:layout_below="@+id/txt_emp_name"

android:padding="6dp" />

<TextView

android:id="@+id/txt_emp_salary"

android:layout_width="wrap_content"

android:layout_height="wrap_content"

android:layout_below="@+id/txt_emp_dob"

android:padding="6dp" />

</RelativeLayout>

<View

android:layout_width="match_parent"

android:layout_height="1dp"

android:layout_below="@+id/layout_item"

android:background="@color/view_divider_color" />

</RelativeLayout>

4) Run

DOWNLOAD : AndroidFragmentSQLite1.zip
